drawDB
drawDB designs database schemas and entity-relationship diagrams, then generates SQL for several database systems.
About drawDB
drawDB is an online tool for designing database schemas and entity-relationship (ER) diagrams. Users build diagrams on a canvas and generate SQL data definition language (DDL) for MySQL, PostgreSQL, SQLite, MariaDB, SQL Server, and Oracle. An existing DDL script can be imported to rebuild its diagram, and diagrams can be exported as SQL, DBML, JSON, or images.
The free editor runs in the browser without an account. Diagrams are stored locally in the browser, so they should be backed up before browser data is cleared. The homepage describes cloud storage, teams, and real-time collaboration as Pro features, and it lists an AI schema assistant without stating which plan includes it. drawDB is also open source and can be self-hosted with Docker on the user's own infrastructure.
Key features
- Visual ER diagram editor with tables, subject areas, and notes on an infinite canvas
- Generates DDL for MySQL, PostgreSQL, SQLite, MariaDB, SQL Server, and Oracle
- Imports a DDL script and rebuilds it as an editable diagram
- Exports DDL, DBML, JSON, or image files from a diagram
- Generates migration scripts from a versioned diagram
- Self-hosting with Docker on your own infrastructure
Best for: Developers and database designers who want to draw schemas in a browser and generate SQL for common database systems without creating an account.
Good for
- Free and open source, and the full editor runs in the browser without an account
- Supports several SQL dialects, with import and export for each
- Can be self-hosted so diagrams stay on the user's own infrastructure
Watch out for
- In the free editor, diagrams are stored locally in the browser and must be backed up manually
- Cloud sync, sharing, and team collaboration are described as Pro features
drawDB at a glance
- Website
- drawdb.app
- Category
- Development › APIs & Databases
- Type
- Online tool
- Pricing
- Not confirmed. Check the site
- Platforms
- Web
- Open source
- Not stated
- Language
- English
- Last checked
- Oct 6, 2026 · Online when checked
- Listed
- Oct 5, 2026
Guides for APIs & Databases
drawDB alternatives
Tools and sites you could use instead, ranked by how closely they match.
ChartDB visualizes database schemas as diagrams and supports data modeling.
Analytical SQL queries can be run with DuckDB, an open-source database system.
Open source
24 alternatives
Create, search, and edit SQLite or SQLCipher database files with DB Browser, an open-source visual database tool.
Multiple databases can be managed with Beekeeper Studio, a SQL editor and database application.
SQLite databases can be viewed, created, and queried online through SQLook.
DBeaver Community manages and queries databases with a free, open-source application.
Popular in APIs & Databases
Well-known listings from the same topic.
API3api3.orgTwiliotwilio.comPocketBasepocketbase.ioBrunousebruno.comMeilisearchmeilisearch.comPostmanpostman.com
drawDB FAQ
Where are my diagrams saved?
In the free editor, diagrams are stored locally in your browser using IndexedDB, so back them up before clearing your browser. With drawDB Pro, diagrams sync to the cloud and across your team.
Can I import an existing schema?
Yes. You can paste or upload a DDL script, and drawDB rebuilds the diagram from it.
Is drawDB free?
The homepage states that drawDB is free and open source, and that the full editor runs in the browser with no account required. It also describes Pro as adding cloud storage, teams, and real-time collaboration. No Pro pricing is stated in the source.
